Penghancur Kerucut Hidraulik Multi-silinder HPT
Based on some design principles of traditional multi-cylinder hydraulic cone crushers like fixed main shaft, eccentric sleeve rotating around main shaft and lamination crushing, HPT Multi-cylinder Hydraulic Cone Crusher makes a breakthrough on its structure. After optimization, the structure improves the performance and crushing capability a lot. Meanwhile, the hydraulic lubrication system of HPT Cone Crusher not only ensures the stable operation but also makes the system control more intelligent.
Fitur Produk: Higher crushing ratio, bigger processing capacity, better granularity and shape of finished products
- Ukuran Masukan: 0-350mm
- Kapasitas: 45-1200TPH
- Bahan: Granit, diabase, basal, kerikil, batu gamping, dolomit, metallic ores and non-metallic ores, dll..
PLC Integrated Control System Makes Operations Simpler
HPT Hydraulic Cone Crusher adopts the advanced PLC electrical system, which can continuously detect the crusher and give alarms, and display various operating parameters. The operator can learn the operating conditions of the crusher in real time. This system not only simplifies the operations of production line and saves the labor cost, but also reduces the operation risk, so that the safety performance of the production line is higher.
Upgraded Structure, Higher Efficiency
Reserving unique structures like the fixed axis and the characteristic that eccentric sleeve rotates around the axis, HPT Hydraulic Cone Crusher further optimizes the transmission parts and lubrication and sealing structures. Jadi, this crusher boasts strong holding capacity, bigger installed power, higher efficiency yet lower noises.
The Principle of Lamination Crushing Brings Better Discharging Size
HPT Hydraulic Cone Crusher adopts the principle of lamination crushing. Not only can the crushing efficiency improve, but also the abrasion of vulnerable parts reduces greatly. The finished products are cubic. Meanwhile, the content of qualified fine particles is high enough. Finished products can better serve as high-quality aggregates.
Multiple Cavity Types Meet Various Production Needs
HPT Hydraulic Cone Crusher has several kinds of cavities suitable for medium-fine or fine crushing of materials. Users can freely make choices among different cavities by changing only a few spare parts like the lining plate, truly achieving that a crusher serves multiple purposes.
Pemrosesan Digital, Presisi Lebih Tinggi
Ada puluhan baris alat mesin pengontrol numerik. Operasi seperti pelat baja’ pemotongan, pembengkokan, perencanaan, penggilingan dan penyemprotan cat semuanya dikontrol secara numerik. Presisi pemesinan tinggi, terutama untuk bagian inti.
Pasokan Suku Cadang yang Cukup, Operasi Tanpa Khawatir
SBM, yang usahanya meliputi produksi dan penjualan, bertanggung jawab atas setiap mesin yang diproduksi oleh diri kita sendiri. Kami dapat menawarkan pelanggan layanan teknis tentang produk dan suku cadang asli untuk memastikan pengoperasian tanpa rasa khawatir.
Prinsip bekerja
When a HPT Multi-cylinder Hydraulic Cone Crusher works, driven by the motor, the transmission shaft rotates under the action of belt pulley and triangular belt. Berikutnya, the transmission shaft drives the eccentric sleeve to make it rotate around the axis. Meanwhile, the eccentric sleeve forces the movable cone to do pendular movement. This movement makes the movable cone and fixed cone sometimes close to, sometimes far away from the rolling wall. Materials are continuously shocked, squeezed and crushed in the crushing cavity between the crushing wall and the rolling wall. Akhirnya, materials are discharged out of the machine when their fineness reaches the discharging standard.
Parameter Produk
| Model | Cavities | Pembukaan umpan (mm) | Minimum discharging size (mm) | Capacities (th) | Maximum installed power (kW) | Dimensi keseluruhan (mm) |
| HPT100 | C1(Extra Coarse) | 140 | 19 | 75-140 | 90 | 1705×1510×1583 |
| C2(Coarse) | 100 | 13 | 60-110 | |||
| M(Medium) | 70 | 9 | 52-100 | |||
| F1(Fine) | 50 | 9 | 50-95 | |||
| F2(Extra Fine) | 20 | 6 | 45-90 | |||
| HPT200 | C2(Coarse) | 185 | 19 | 145-250 | 160 | 2135×1750×1927 |
| M(Medium) | 125 | 16 | 135-235 | |||
| F1(Fine) | 95 | 13 | 115-220 | |||
| F2(Extra Fine) | 75 | 10 | 90-190 | |||
| HPT300 | C1(Extra Coarse) | 230 | 25 | 220-440 | 250 | 2725×2110×2871 |
| C2(Coarse) | 210 | 19 | 190-380 | |||
| M(Medium) | 150 | 16 | 175-320 | |||
| F1(Fine) | 105 | 13 | 145-280 | |||
| F2(Extra Fine) | 80 | 10 | 110-240 | |||
| HPT400 | C1(Extra Coarse) | 295 | 30 | 300-630 | 315 | 2775×2370×2295 |
| C2(Coarse) | 251 | 25 | 285-560 | |||
| M(Medium) | 196 | 20 | 250-490 | |||
| F1(Fine) | 110 | 13 | 180-345 | |||
| F2(Extra Fine) | 90 | 10 | 135-320 | |||
| HPT500 | C1(Extra Coarse) | 330 | 38 | 425-790 | 400 | 2800×3480×4050 |
| C2(Coarse) | 290 | 30 | 370-700 | |||
| M(Medium) | 210 | 22 | 330-605 | |||
| F1(Fine) | 135 | 16 | 270-535 | |||
| F2(Extra Fine) | 95 | 13 | 220-430 | |||
| HPT800 | C1(Extra Coarse) | 350 | 38 | 570-1200 | 630 | 3970×3345×4235 |
| C2(Coarse) | 299 | 32 | 520-1050 | |||
| M(Medium) | 265 | 25 | 475-950 | |||
| F1(Fine) | 220 | 16 | 370-800 | |||
| F2(Extra Fine) | 150 | 13 | 310-600 |
Catatan:
Gambar produk dan parameter tentang model, data, performa dan spesifikasi di situs web ini hanya untuk referensi. Ada kemungkinan SBM dapat melakukan perubahan atas informasi tersebut di atas. Untuk pesan tertentu, silakan merujuk ke objek nyata dan manual pengguna. Tanpa instruksi khusus, SBM berhak untuk menjelaskan semua data yang terlibat dalam website ini.
