SCM Ultra İnce Öğütme Değirmeni

Ev » Ürünler » SCM Ultra İnce Öğütme Değirmeni

SCM Ultra İnce Öğütme Değirmeni yeni bir süper ince tozdur (325-2500 örgü) Öğütme değirmeni üretiminde yılların deneyiminin birikimiyle geliştirilen üretim ekipmanları, İsveç'in ileri makine imalat teknolojisini özümseyen, ve uzun yıllar süren testlerden ve iyileştirmelerden geçiyoruz. The SCM Ultrafine Grinding Mill is the result of combination of advanced Chinese and Swedish technologies. Bu sırada, it symbolizes the new development and new science in the grinding world.

Ürün Özellikleri: Ultrafine powder, wide applications, excellent environmental effect

Giriş Boyutu: 0-20mm
Kapasite: 0.5-25TPH
Malzeme: kireçtaşı, kalsit, dolomit, petrol kömürü, alçıtaşı, barit, mermer, talk, kömür tozu, vesaire.

Çevrimiçi sohbet

Verim

Higher Yielding, Daha Düşük Enerji Tüketimi

Newly designed grinding curves of grinding roller and grinding ring further enhance the grinding efficiency of SCM Ultrafine Grinding Mill. With the same fineness and power, the production capacity is 40% higher than that of jet grinding mill and stirred grinding mill, and the yield is twice as large as that of ball grinding mill. Fakat, the system energy consumption is only 30% of the jet grinding mill.

Adjustable Fineness Between 325-2500meshes

SCM Ultrafine Grinding Mill’s cage-type powder selector adopts German technologies, which effectively increases the precision of powder separation. Ek olarak, multi-head cage-type powder selector can be configured according to the users’ requirements on yield, fineness and sieving rate. The product fineness can be adjusted between 325-2500 meshes, and the screening rate can achieve d97≤5μm once.

No Rolling Bearing & Screw in Grinding Chamber

There is no rolling bearing and screw inside the chamber of SCM Ultrafine Grinding Mill, so users are free from worries about damages on bearing or its sealing parts, and there is no machine damage problem caused by loose screws. The lubricating device is installed outside of the main shaft, so that lubrication without shutdown can be realized externally, and the production can be continued for 24h.

Dust Removal by Pulse Collector Makes Operation More Eco-friendly

SCM Ultrafine Grinding Mill is equipped with efficient pulse dust collector, so no dust pollution generates during operation of the entire milling system. Silencer and noise elimination room are configured to reduce noises. The production is organized fully according to the national environmental protection standards.

Dijitalleştirilmiş İşleme, Daha Yüksek Hassasiyet

Onlarca satır sayısal kontrollü takım tezgahı var. Çelik levhalar gibi işlemler’ kesme, bükme, planlama, frezeleme ve boya püskürtme işlemlerinin tümü sayısal olarak kontrol edilir. İşleme hassasiyeti yüksektir, özellikle çekirdek parçalar için.

Yeterli Yedek Parça Temini, Sorunsuz Çalışma

SBM, İşletmeleri üretim ve satışı kapsayan, Kendi ürettiğimiz her makinenin sorumluluğunu alır. Sorunsuz çalışmayı sağlamak için müşterilerimize ürünler ve orijinal yedek parçalar hakkında teknik hizmetler sunabiliriz..

Çalışma prensibi

After hammer crushers break large bulky materials to smaller ones, elevator works to send materials to material bin. Sonraki, materials are sent to the grinding mill evenly and they would fall onto the dispersing plate firstly. When the grinding mill runs, dozens of grinding rollers start to rotate and roll. Under the action of centrifugal force, materials on the dispersing plate are then thrown to the rim and drop to the grinding chamber. In the circuit, materials would be squeezed and ground. After being ground several times, materials are blown into the powder selector by airflow. Toz seçicinin pervanesinin etkisi altında, İnceliği sağlayamayan malzemeler tekrar öğütme odasına gönderilerek bir kez daha öğütülecek, nitelikli tozlar ise siklon toz toplayıcı tarafından toplanıp alttan bitmiş ürün olarak boşaltılacaktır.. Some remaining powders would be collected by impulse dust remover and they may stick to the surface of filler-bag. Bu yüzden, next, high-pressure airflow controlled by the impulse valve blows the filler-bag to make it swell and shake violently. This sudden shake can help kick off materials on the filler-bag and collect them as finished products. After filtering, the airflow would be discharged to the air. This system adopts an open circuit and runs under negative pressure.

Ürün parametreleri

Modeli	SCM800	SCM900	SCM1000	SCM1250	SCM1680
Working diameter (mm)	Φ800	Φ900	Φ1000	Φ1250	Φ1680
Max feed size (mm)	≤20	≤20	≤20	≤20	≤20
Son boyut (örgü)	325-2500	325-2500	325-2500	325-2500	325-2500
Output (kgh)	500-4500	800-6500	1000-8500	2500-14000	5000-25000

Modeli		SCM800	SCM900	SCM1000	SCM1250	SCM1680
Ana motor	Güç	75	45×2	132	185	315
Analytical engine (FM motor)	Güç	18.5	18.5	30	15×4	18.5×5
Blower motor	Güç	45	55	75	55×2	90×2
Kırıcı	Modeli	PC400×600	PC400×600	PC400×600	PC600×800	PC600×800
Kırıcı	Güç	18.5	18.5	18.5	45	45
Elevator	Modeli	TH-200	TH-200	TH-300	TH-300	TH-300
Elevator	Güç	3	3	4	5.5	7.5
Titreşimli besleyici	Modeli	300×60×1.8 Φ159-1.8	300×60×1.8 Φ159-1.8	300×60×1.8 Φ159-1.8	400×80×2 Φ219-2	400×80×2.8
Titreşimli besleyici	Güç	1.5/3	1.5/3	1.5/3	1.5/3	2.2
Discharge screw conveyor	Modeli	LS219-4.5/LS219-3	LS219-5.8	LS219-6.9/LS219-5	LS219-5	LS273-8.6
Discharge screw conveyor	Güç	3	3	4	3×2	5.5×2
Discharge valve	Modeli	ZJD-200	ZJD-200 ZJD-250	ZJD-200 ZJD-250	ZJD-250	ZJD-300 ZJD-200
Discharge valve	Güç	0.75	0.75 + 1.1	0.75+ 1.1	1.1	1.5+0.75
Pulse dust collectors	Modeli	DMC120/DMC16	DMC16	LDMC25	LDMC45	LDMC400×2
Air compressor	Modeli	KSH150D/LG1.5-8	KSH240D/LG2.4-8	KSH300D/LG3.6-8	LG6.2-8	LG10-8
Air compressor	Güç	11	15	22	37	55
